Seccionadora tablero F100A
CNC panel saw with circular disc, designed for precise cutting and squaring of sandwich panels and technical boards.
The machine incorporates a CNC circular saw head with rotation from 0 to 90°, full control of X, Y and Z axes, and a robust structure designed for continuous industrial operation.
The machine allows longitudinal and transverse cuts, ensuring high dimensional accuracy, repeatability and clean cutting finish, even in composite materials such as GRP-PU-GRP.
It is equipped with an industrial CNC control with touchscreen, easy programming and full parameterization of cutting speeds, depths and travel paths.
The machine includes a full peripheral safety enclosure and is prepared for panel aspiration and clamping systems.
Main Technical Specifications
Working area (X × Y x Z):
3000 × 1200 x 210 mm
Cutting system:
CNC circular saw head
Fixed perpendicular cutting from 0 to 90°
Automatic height control (Z axis)
Controlled axes:
X, Y, Z and 0–90° rotation by CNC
Interpolated movements for maximum precision
Control:
Industrial CNC with touchscreen
Manual, coordinate-based and CAM automatic programming
Fixed cycle capability
Cutting speed and depth adjustment
Worktable:
Vacuum table
Optional suction cups for panel clamping
Compatible materials:
GRP-PU-GRP sandwich panels
Technical boards and composite materials
Safety:
Full peripheral enclosure
Prepared for integration of CE safety systems
Main applications:
Panel squaring and cutting
Custom cutting in X, Y and Z
Dimensional finishing after horizontal splitting
